Small. Handy. Powerful.
The analyzer is designed for measuring SWR (standing wave ratio), return loss, as well as other parameters of cable and antenna systems in the range of 100 kHz to 230 MHz.
The following tasks are easily accomplished by using this analyzer:
- Rapid check-out of an antenna in the field or stationary conditions.
- Tuning an antenna to resonance.
- Comparing characteristics of an antenna before and after a specific event (rain, hurricane, etc.).
- Measuring capacitance or inductance of reactive loads.
Warranty coverage by the RigExpertCare™
RigExpert Stick 230.
Specifications
Frequency range: 0.1 to 230 MHz
Frequency entry: 1 KHz resolution
Measurement for 25, 50, 75, 100, 150, 200, 300, 450, and 600-Ohm systems
SWR measurement range: 1 to 100 in numerical modes, 1 to 10 in chart modes
R and X range: 0…10000, -10000…10000
Display modes:
- SWR, return loss, R, X, Z, L, C, Magnitude and Phase Angle at single frequency.
- SWR chart, 100 points.
- SWR chart at fixed HAM bands by IARU Regions, 100 points.
- Multé mode – to check your multiband antenna promptly.
RF output:
- Connector type: UHF (SO-239).
- Output signal shape: square, 0.1 to 230 MHz.
- Output power: -10 dBm (at 50 Ohm load).
Power:
- One 3.7V Li-Ion battery, type 18650
- When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources
Interface:
- 200×200 monochrome e-paper display
- 2×3 keys on the water-proof keypad
- English menus and help screens
- USB connection to a personal computer
Bluetooth: v.4.2 BLE Single-mode, Class B
Dimensions: 185 mm x 40 mm x 33 mm (7,3 in x 1,6 in x 1,3 in)
Operating temperature: 0…40 °C (32…104 °F)
Weight: 185 g (6,5 Oz) with battery
Warranty: 2 years
GTIN-13: 4820185420259
RigExpert Stick is made in Ukraine.
*All specifications are subject to change without notice or obligation.
RigExpert Stick 230.
Inside The Box
- RigExpert Stick 230 antenna analyzer (with a Li-ion battery type 18650)
- quick start guide
- neck strap
- USB cable
-
RigExpert Stick 230.
Users ManualStick 230 is an antenna and cable vector analyzer. The analyzer allows you to measure various parameters of antennas, cables, lines, filters and many others in the frequency range from 100 kHz to 230 MHz.
The Stick 230 analyzer has a compact size and lightweight, which is great for using the analyzer both in the home and in the field.
The main parameters of the Stick 230 analyzer:
- Operating frequency: 100 kHz – 230 MHz
- Size: 185 * 40 * 33 mm (7,3 in x 1,6 in x 1,3 in)
- Weight: 185 grams (6.5 Oz) (unpacked, with battery installed)
- Type of antenna connector: SO-239
- Number of Enter Keys: 6
- Display: monochrome e-paper, 200 * 200 pixels.
- Type of battery used: Li-ion 18650 (included)
- PC Connector Type: USB 2.0 Type-C
- Charging Port Type: USB Type-C
- Bluetooth Availability: Yes, Bluetooth ver. 4.2 BLE Single-mode, Class B
- Battery Charge Time: 3 hours.
- RF Power: -10 dBm (at 50 Ohm load)
- Minimum frequency step: 1 kHz
- Operating temperature: 0…40 °C (32…104 °F)
